Cosman G4 - Other Device Connections and Indicators

Cosman G4 Radiofrequency Generator Service Manual (SPI 11291 Rev A)
2
RF Electrode Output Connection 2 (on front panel)
3
RF Electrode Output Connection 3 (on front panel)
4
RF Electrode Output Connection 4 (on front panel)
Other Connections
Footswitch Remote Control Connection
Equipotential Jack Terminal
USB Connection (Printer or Memory Stick)
Readings and Indicators
Output On Indicator Light
°C
Temperature (Degrees Celsius)
Ω
Impedance (Ohms)
V
Voltage (Volts)
mA
Current (Milliamps)
W
Power (Watts)
ms
Pulse Duration/Width (millisecons)
Hz
Pulse Rate/Frequency (Hertz = 1/Seconds)
min
Time (Minutes:Seconds)
Section 1
