Cosman G4 Radiofrequency Generator Service Manual (SPI 11291 Rev A)
Selected parameters of the Pulsed RF waveform are shown schematically in the illustration below.
1/Pulse Rate Pulse Width
Time
RF e/ RF off puls
burst
Set Time
Voltage
The Pulsed RF Settings Screen is shown below.
Press “Ok”:
A
ccept selected
settings.
Select settings from
drop-down menus
Pulsed RF
Screen
Section 8.3
Custom Setting
Keypad
Select “Custom”
from a setting
drop-down menu
Section 8
