SYMBOLS FOR USER FUNCTIONS
Symbol Description
Party
Eco
Holiday
Floor drying is active
Automatic switchover to summer mode
Heating with constant stand pipe temperature is active
Remote activation
Boost heating
SYMBOLS FOR TEMPERATURE AND DATA OVERVIEW
Symbol Description
Measured temperature
Calculated or set-point temperature
Indoor (Room) temperature
Outdoor temperature
Stand-pipe temperature
Return-pipe temperature
Boiler temperature
Mixing valve - closing (flashing indicates trend for closing)
Mixing valve - opening (flashing indicates trend for opening)
Circulation pump
T1, T2, T3, T4
TR
TA
TQ
Temperature measured on sensor T1, T2, T3 or T4.
Temperature measured on room unit RCE.
Outdoor temperature, acquired t BUS connection.
Boiler temperature, acquired from BUS connection.
- day of drying
- drying duration (days)
