Cosmo DN 25 - Hydraulic Schemes; Scheme 360 - Standalone mixing circuit

ENG
43
Hydraulic and electric schemes J5060403 v1.2
HYDRAULIC SCHEMES
CAUTION: Installation schemes show the operation principle and do not contain all
auxiliary and safety elements! When installing you have to follow valid rules!
IMPORTANT
For controller operation a room unit is not needed.
Room unit connection is described on page 40.
Optional sensor. Not needed for controler operation.
Scheme 360 - Standalone mixing circuit
T3
8
7
CMP25
2
3
0
V
~
5
0
H
z
L
N
T4
9
T2
5 6
Optional: RCE
