104
Please refer to the following sheet for detailed information.
You need to check the box to enable/disable Video Loss function. By
default Video loss function enable for all channel. Please select a
channel from the dropdown list.
Video Loss function becomes activated in the specified periods. See
Figure 5.32.
There are six periods in one day. Please draw a circle to enable
corresponding period.
Click OK button, system goes back to Video Loss interface; please click
save button to exit.
System only memorizes one event during the anti-dither period. The
value ranges from 5s to 600s.
There are six levels. The sixth level has the highest sensitivity.
System auto activates selected channels to record once an alarm occurs
System can delay the record for specified time after alarm ended. The
value ranges from 10s to 300s.
Here you can set PTZ movement when alarm occurs. Such as go to
preset X. See Figure 5.33.
You need to check the box here to enable this function. System begins
1-wiindow or multiple-window tour display among the channel(s) you
set to record when an alarm occurs.
System can pop up a message to alarm you in the local host screen if
you enabled this function.
If you enabled this function, System can send out an email to alert you
when an alarm occurs.
System can upload the alarm signal to the server (Including alarm
server.
Check the box here to enable this function. The buzzer beeps when an
alarm occurs.
Expressed alarm occurs if the selected channel or video capture channel,
the video file up to a FTP server.
Check the box here, system can record Video Loss event log.
