5.9.2. Network
5.9.2.1. TCP/IP
5.9.2.1.1. TCPIP
TCP/IP interface is shown as in Figure 5.17.
Figure 5.17
Please refer to the following sheet for detailed information.
There are two modes: static mode and the DHCP mode.
⚫ The IP/submask/gateway is null when you select the DHCP
mode to auto search the IP.
⚫ If you select the static mode, you need to set the
IP/submask/gateway manually.
⚫ If you select the DHCP mode, you can view the
IP/submask/gateway from the DHCP.
⚫ If you switch from the DHCP mode to the static mode, you need
to reset the IP parameters.
⚫ Besides, IP/submask/gateway and DHCP are read-only when the
PPPoE dial is OK.
