APPENDIX (Complete Icon Library)
ICON NAME DESCRIPTION OFF/ON
FILTER
Displays the current status of the
filter life.
FILTER CHANGE
Displays when a filter change is
required
FILTER CHANGE
Touch to CHANGE FILTER
FILTER CHANGE
Touch to CHANGE FILTER
FULL CYCLE
COMPLETE
Indicates that the FULL CYCLE service
is COMPLETE
GRAMS
Touch to select GRAMS as UOM
HELP
Touch to launch the HELP Menu
HELP
Provides Firmware version
HIGH COUPLER
Touch to select the HIGH SIDE coupler
only
HOME
Touch to launch the HOME screen
INJECTION
Notifies the user to INJECT oil and/or
dye at this point in the service
INTERNATIONAL
Touch to select INTERNATIONAL UOM
KGCM2
Touch to select KGCM2
KGS
Touch to select KGS as UOM
KPA
Touch to select KPA
LANGUAGE
Touch to select LANGUAGE
LBS
Touch to select LBS as UOM
LBS:OZ
Touch to select LBS:OZ as UOM
LOW COUPLER
Touch to select the LOW SIDE coupler
only
MAINTENANCE
Touch to launch the MAINTENANCE
menu
METRIC
Touch to select METRIC UOM’s
MPA
Touch to select MPA
NOT NOW
Touch to postpone suggested
operation
Open Ball Valve
Press to Open Ball Valve
OZ
Touch to select OZ as UOM
ICON NAME DESCRIPTION OFF/ON
AIR PURGE
Touch to select AIR PURGE
AMERICAN
Touch to select AMERICAN Units
BAR
Touch to select BAR
BOTH
COUPLERS
Touch to select BOTH couplers
° C
Touch to select CELSIUS
CALIBRATION
Touch to select CALIBRATION
CAR SYSTEM
HEALTH MODE
Touch to launch CAR SYSTEM HEALTH
MODE
CHANGE TANK
The CHANGE TANK icon notifies the
user to change the tank
CHANGE UOM
Touch to change the unit of
measurement
CHARGE
Touch to perform a CHARGE service
CHARGE
COMPLETE
Indicates that the CHARGE service is
COMPLETE
Charge Low
Side
Press to select Low Side Charging
CHECK SCALE
COMPLETE
The SCALE CHECK COMPLETE notifies
users that a scale check is complete
Close Ball
valve
Press to close ball valve
CLOSE
COUPLER
The CLOSE COUPLER icon notifies
the user to close the coupler during
a recharge service
CLOSE HP
Notifies the user to CLOSE HP valve
during a CHARGE service
CLOSE VALVE
Notifies user to CLOSE VALVE
CONNECT HP
Notifies user to connect HP port
during tank refill
CPS FILTER
CPS FILTER
DISCONNECT
COUPLERS
Notifies the user to DISCONNECT
COUPLERS
DRAIN OIL
The DRAIN OIL icon notifies the user
that oil is draining from the vehicle
END-USER
AGREEMENT
Touch to access the End-User License
Agreement
ERROR
Displays when there is an ERROR
° F
Touch to select FARENHEIGHT
FAILED
Indicates that a given operation FAILED
To Next Page
