7
SPECIFICATIONS
Power 115V 60Hz
Compressor 2/3 HP Twin Cylinder Oil-less
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 10 Ft. (3.0 m), Barrier Type
Refrigerant For Use With R-1234yfyf Only
ASHRAE Refrigerant Code A1
Maximum Recovery Rate Up To 1 Lb (0.453 kg) per minute
Storage Tank 1 x 30 lb DOT tank (specications on page 8)
Display 7” Touch Screen with 256 color graphical display
Construction
Sheet metal frame with molded plastic panels. 1 piece handlebar, 4” front casters and 10” foam-lled rear tires for
exceptional maneuverability
Operating Temperature Range 50°F to 122°F (10°C to 50°C)
Operating Humidity Range 0% to 95% (Non-Condensing)
Dimensions (H x W x D) 43.6” x 22.6” x 28.9” (1.1 x 0.57 x 0.28 m)
Weight (Without Packaging) Gross Weight: 208 Lbs (With Packaging)
Warranty (Maxxair™ 1-2-3)
See Page 51
Stage 2
Maximum Free Air Displacement 2 CFM at 60 Hz / 48l/m @ 50 Hz
Motor Size (HP), RPM @ 50/60Hz 1/3 HP (@1440 RPM/50 Hz Or 1720 RPM/60 Hz)
Voltage, Watts, Amps 110~120VAC Or 220VAC @50/60 Hz
Ignition Proof Construction Meets ANSI 12.12.1
Ultimate Vacuum 10 Microns
Refrigerant Class A1, A2
Operating Temperature Range 32°F to 125°F (0°C to 52°C)
Storage Temperature Range 32 F to 104 F (0 C to 40 C)
Pro-Set® Vacuum Pump Oil Capacity 11 oz (330 ml)
Intake Fittings 1/4” & 3/8” SAE Male, ACME 1/2”
High Side Gauge (Analog) 0 ~ 550 psi, (38 bar ~ bar), 3792 ~ kPa
Low Side Gauge (Analog) 0 ~ 350 psi, (0 ~ 24 bar), 0 ~ 2400 kPa)
Motor Thermally Protected Yes
INSTALLED VACUUM PUMP SPECIFICATIONS
MX3030 OVERALL SPECIFICATIONS
Tare (Empty) Weight Mode Yes
Units (Weight) Readout lb & oz, or kg & gm
Weight Accuracy 0.015% of Reading [or ± 0.25 oz (10 g) whichever >]
Display Resolution (Increments) 0.25 Oz (10 g)
Platform Dimensions 8.75˝ x 8.75˝ (22.3 x 22.3 cm)
Overload Protection Mechanical (Internal Overload Stop)
Calibrated To NIST Standards Yes
Declaration Of Conformity EN 61326-1:2013, CISPR 11:2009/A1:2010
INSTALLED REFRIGERANT SCALE SPECIFICATIONS
