MACHINE LAYOUT
FRONT VIEW
CONTROL PANEL
Storage Tray
For Small Tools
Or Fittings
3.5” High Side
Gauge (Analog)
3.5” Low Side
Gauge (Analog)
7” Color Touch Screen
LCD Display
Machine Model #
RCA Port (For Temperature
Probe #TMX2P Accessory
(Included)
Power (On/Off)
Button
USB Port
