(2) Installation method
Make sure that the mounting structure (wall, rack, etc) is suitable to
support the inverter weight. Follow the mounting guidelines below:
(a) If the location permits, install the inverter vertically.
(b) If the inverter cannot be mounted vertically, it is allowed to be tilted
backward by Max. 15°.
(c) Do NOT mount the inverter forwards.
(d) Do NOT mount the inverter in a horizontal position.
(e) Do NOT mount the inverter upside down.
Figure 3-2 Mounting the inverter properly
