58
The “ReactiveMode” menu has 6 submenus (Figure 5-16), including “1
None”, “2 Dispatch”, “3 Q Set”, “4 PF Set”, “5 PF(P) Set” and “6 Q(U) Set”.
1 None
2 Dispatch
3 Q Set
4 PF Set
Figure 5-16 Submenus of ReactiveMode
1. None: No mode/Disable reactive mode
2. Dispatch: Remote power dispatch mode
Note: When the dispatch mode is selected, the reactive parameters of the
inverter will change according to the remote change order, including
ActivePower, PF and Q values.
1 None
→ 2 Dispatch
3 Q Set
4 PF Set
ActivePower(%)
100.0
→ReactiveMode
None
Figure 5-17 Enable the dispatch function
3. Q Set: Set the Q mode
Note: Change the reactive power by adjusting the Q value (reactive
compensation)
4. PF Set: Set the PF mode
Note: Change the reactive power by adjusting the PowerFactor
