CPS SC Series - Page 64

60
Table 5-3(b) Protection Parameters Table for CPS SC14KTL-DO/US-208
No.
LCD indication
Description
Setup range (lower limit,
default & upper limit)
1.
V.MaxI (V)
Class I Max. grid voltage
{224.0, 228.8, 249.0}
2.
VmaxTripTI (S)
Class I Max. trip time
{0.08, 1.00, 600.00}
3.
V.MinI (V)
Class I Min. grid voltage
{104.0, 183, 187.0}
4.
VminTripTI (S)
Class I Min. grid voltage
trip time
{0.08， 2.00, 600.00}
5.
V.MaxII (V)
Class II Max. grid voltage
{0, 249.6, 485.0}
6.
VmaxTripII (S)
Class II Max. grid voltage
trip time
{0.08, 0.16, 600.00}
7.
V.MinII (V)
Class II Min. grid voltage
{100.0, 104, 183.0}
8.
VminTripTII (S)
Class II Min. grid voltage
trip time
{0.08, 0.16, 600.00}
9.
F.MaxI (Hz)
Class I Max. grid
frequency
{60.00, 60.5, 63.00}
10.
FmaxTripTI (S)
Class I Max. grid
frequency trip time
{0.08, 0.16, 600.00}
11.
F.MinI (Hz)
Class I Min. grid
frequency
{57.00, 59.3, 60.00}
12.
FminTripTI (S)
Class I Min. grid
frequency trip time
{0.08, 0.16, 600.00}
13.
V.MaxRecover
Max. grid voltage recover
value
{208.0, 225, 249.0}
14.
V.MinRecover
Min. grid voltage recover
value
{104.0, 186, 208.0}
