22
Figure 3-11 Mount the Main Enclosure on the Bracket by Lifting Sling
B. Manual mounting: Two people are needed to properly lift by the
handle positions marked in Figure 3-12 and mount the inverter
onto the bracket.
Figure 3-12 Grab Handle Position
