25
D. Tighten the M8 nuts following the following order
1→2→3→4 and repeat to confirm that all the nuts are
tightened securely. (Figure 3-17)
Figure 3-17 Tighten the M8 nuts
CAUTION!
The total weight of the inverter is approx.80kg (176 pounds).
Please ensure the mounting is properly installed before hanging
the inverter on the bracket.
CAUTION!
Please be careful with your hand when pushing the unit.
