Creality CR-10 Smart User Manual

7.Install the touch screen 安装触摸屏
1
2
Caution
●Do not connect or disconnect the cables when the machine is powered on.
●当机器通电时，请勿连接或断开连接线。
3
x 1
｜Touch screen 触摸屏
3
1. Connect the FFC on the base with the touch screen.
1、把底座的排线与触摸屏连接起来
2. Fix the three screen locks on the touch screen to the studs of the base and press them into place.
2、将触摸屏上的三个屏幕锁固定在底座的螺丝柱上，并按压到位。
07

Creality CR-10 Smart Specifications

General

Build Volume	300 x 300 x 400 mm
Layer Resolution	0.1-0.4 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Touchscreen	Yes
Bed Temperature	up to 100°C
Nozzle Temperature	up to 260°C
Frame Material	Aluminum
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Power Supply	350W
Machine Dimensions	578 x 522 x 648 mm
Machine Weight	14 kg
Connectivity	Wi-Fi, USB
Supported Filaments	PLA, TPU, PETG
Bed Leveling	Automatic
