Creality CR-6 SE - Install the Gantry Frame

Twist the coupling to raise the X axis
to the position as picture shown.
拧动联轴器使X轴上升到如图所示位置。
x 1
Gantry Frame｜龙门架
2
x 1
Base Frame｜底座
1
Install the Gantry Frame
安装龙门架
1
15
M5*45 Sems Screw
M5*45组合螺丝
×4
1
15 15
2
X-axis bottom profile
X轴底部型材
Two Z-axis profiles, installed on the
inner step of the X-axis bottom profile.
两根Z轴型材，靠X轴底部型材内侧台阶安
装。
