CreatBot DX - Frequently Asked Questions; Routine Maintenance; Print PLA and ABS

- 28 -
- 29 -
Frequently Asked Questions
Routine Maintenance Paving Kapton
Frequently Asked Questions
1. Frequent cleaning stains on the rail.
2. Lubricate the four guide rail.
3. Frequent cleaning feeder gear.
Nozzle
Bed
Close bed
Adhesion
Cooling
Tape
Enclosed
PLA
200 ℃
45 ℃
Timed close
None/Brim
Max. 100%
masking
Can open
ABS
240 ℃
90 ℃
Always
Brim/Raft
Max. 50%
Kapton
Enclosed
Print PLA and ABS
* The data is only for reference, different environmental data will be different.
1. Clean the platform first.
2. Kapton is a double-sides adhesive.
3. Paste the first side on platform.
4. Then another side.
5. Pierce the bubble.
Notice: Don’t add too much lubricating
oil.
Tip: Kapton temperature
resistance up to 120 ℃ ,
the film can be reused until
not sticky so far.
