Specifications
Model
DM
DM Plus
DX
DX Plus
DE
Build Size
250*250*300
250*250*450
300*250*300
300*250*520
400*300*300
Nozzles
Single/Dual
Single/Dual/Tris
Single/Dual
Diameter
0.3~1.0mm (other sizes can be customized)
0.3~1.5mm
Temperature
250 ℃ (300℃ extruder update supported)
Hot bed
120 ℃ (can be closed after certain layers)
Min. Layer
0.04mm (less than 0.04 is not recommended)
Accuracy
X 、Y 、 Z axis 0.01mm
Print Speed
120mm/s (inner/outter, top/bottom, fill, first layer speed can be set separately)
Travel Speed
200mm/s
Materials
PLA 、 ABS 、 PVA (dissolve), Nylon, PS and so on (<350 ℃ )
Fila. Diameter
3.0mm (1.75mm optional)
Keypad
No
Yes (nine key)
Auto Turnoff
No
Yes (pwr manager + relay)
Continue Play
No
Yes (Power outage, lower plate and save data)
Fila. Check
Yes (pause printing when filament finish, and lower platform)
Adju. Head
Yes (height-adjustable-nozzles)
OS
Windows, Linux, Mac OS, OSX
Languages
Chinese, English, French, multi-language
Software
CreatWare Muti-language
File Format
STL, OBJ, GCode, Amf
Chipset
Atmega 2560-16AU (AVR 8 Bit 16MHz ，256KB Flash)
Display
128*64 monochrome multi-language (support color TFT)
Pwr Supply
110~220V 360W
Double Pwr
Dimension
370*420*530
370*420*680
420*380*570
420*380*790
590*430*570
Weight
25 Kg
30 Kg
28 Kg
35 Kg
45 Kg
Frequently Asked Questions
not over 120℃, and you can close the bed above 100mm.
3. The model not stick on the platform ?
Please paste masking paper or Kapton on the platform, or the nozzle is too far
away from the platform, or the bottom of the model is not flat.
4. No or less silk coming on the first layer ?
The distance between nozzle and platform is too small, or the filament has not
been sent to the nozzle.
5. Why nozzle is not spit silk ?
The filament is not pressed or too tight, or print temperature is too low, or the
filament feeder not working.
6. How to prevent model become warped ?
Increase hot bed temperature or use Kapton, or change platform adhesion
type to Raft, or cover the baffle, or reduce indoor ventilation.
7. How far from nozzle to platform appropriate ?
Distance should be 0 in theory, but there is no absolute flat platform, so the
distance should +-0.1mm. Finally, with the actual printing effect as the
standard, too close will lead to a silk blocked, too far will cause the model not
stick on the platform.
8. How to determine whether the temperature is too high ?
PLA temperature is too high will appear liquefaction, ABS will be the carbide,
that will block the nozzle.
9. What reasons will causing nozzle blocked ?
Filament are impurities or print environment dust too much, bad of thermal
conductivity between the nozzle and the heating block.
10. Model surface is loose with crack ?
The layer is too high or the printing speed too fast, nozzle temperature too
low or filament press nut too loose, or filament is wrapped.
11. How to print a small model ?
Multiple the model, and print them at a time.
12. Dual color model not aligned ?
Adjust offset of second nozzle in machine settings.
13. Dual color model color interference ?
Align two nozzle in vertical direction
14. There is too much silk drag on the model ?
Please enable filament retraction, and specified proper retract speed, and
distance, the retract distance should not less than 4mm, and the speed not
less than 10mm/s.
