Notice
Notice ················································3
Machine Diagram
Front and Back·························4
Hotend / Feeder ·····················5
Hardware Installation
Unpacking·································6
Install Build Platform ············· 7
Install Feeder ····························· 8
Printer Operation
LCD Screen ································ 9
Keypad / Knob························ 9
LCD Menu Tree ·····················10
Leveling Platform ················ 11
Paving Crepe Paper ············· 11
Load Filament························12
Unload Filament···················13
Software Operation
CreatWare Setup·················· 14
Quick Print UI ······················· 15
Print Your First Model········15
Full Setting UI ······················· 16
Mouse Operation ················ 17
Model Rotate/Scale ············ 18
Model Mirror··························19
View Mode ······························ 19
Right Click on Model ············ 20
Toolpath Structure ················20
Basic Setting ··························· 21
Advanced Setting·················22
Expert Setting ························ 23
Skirt/Brim/Raft ······················ 24
Plugins ····································· 24
Start/End GCode··················25
Dual Head Printing ·············· 25
Align Dual Head Horizon ··· 26
Align Dual Head Vertical ···· 27
Add Multi Type Printer ······· 27
Frequently Asked Questions
Routine Maintenance ········· 28
Print PLA and ABS ··············· 28
Paving Kapton ······················ 29
Change Fuse ·························· 30
Adjust Z Limit ························ 30
Hardware Troubleshoot·····31
Printing Troubleshoot ········ 32
Specifications ······························ 33
CONTENTS
Read First
Thank you for choosing CreatBot 3D printer!
This manual contains important information about the installation, use,
maintenance and common problems of CreatBot 3D printer. Please read this
manual carefully before using 3D printer. All losses caused by the breach of the
notes and the operation process of the operation process will be borne by the user.
Please use the filament provide by CreatBot, or high quality filament of third
manufacturers. Due to the use of third party inferior material caused by the failure
of the printer, the loss will be borne by the user.
Software running environment, 2G or above processors, at least 1G memory,
compatible with Windows, MAC, or Linux, please use memory as much as possible.
I wish you a fun with CreatBot!
Danger Warning
The nozzle's temperature will reach 300 degrees, don't touch.
The platform's temperature will reach 120 degrees, don't touch.
Please make sure that the printer connected to the ground.
Do not attempt to open the case, be careful of electric shock.
Working Environment
The 3D printer can work in the indoor environment of 5 ℃ to 30 ℃.
Long-term not use of the printer, be sure to dust, moisture.
Long-term not use of the filament, please be sealed to prevent deterioration.
Icon conventions
Tip icon to remind users to have a good method or technique.
Note icon, to remind the user must be given adequate attention.
Prohibition icons, prevents users from unauthorized operation.
