Technical Specifications & Troubleshooting B-1
B
Appendix
Technical Specifications & Troubleshooting
NOMAD Jukebox
DAP-6G01
Size (W x H x D)
❑
5" x 5" x 1.5"
Weight
❑
14 oz without batteries
Memory
❑
8 MB DRAM buffer
Capacity
❑
6 GB hard drive (100 hours at 128Kbps
encoding)
Battery Life (playback time)
❑
4 hours* of continuous playback of
songs which are encoded at 128kbps
when fully charged
❑
Battery life may be reduced:
❑
If songs with a higher bitrate are
played
❑
If EAX is turned on.
❑
If operations such as navigation, skip
forward/backward etc. are used
frequently
❑
If backlight is turned on for more
than the default setting of 10 secs
* Based on usage with NiMH rechargeable batteries,
alkaline batteries are not recommended because
they are not suitable for high power consumption
required by NOMAD Jukebox. Using alkaline
batteries may result in a playback time shorter than
1 hour
Interface
❑
USB digital data port offering up to 500
KBps transfer rate
Playback Formats
❑
MP3**
Signal to Noise
❑
>90 dB
Frequency Response
❑
20 Hz~20000 Hz
Harmonic Distortion
❑
<0.1%
Operating System/Firmware
❑
Upgradeable via Internet
Line Input
❑
1/8" stereo minijack
Line outputs
❑
2 x 1/8" stereo minijack for front and
rear speakers
Headphone Out
❑
1/8" stereo minijack, 100 mW
LCD Display
❑
Large 132 x 64 pixel backlit display
Data Connector
❑
USB
EAX
❑
Environmental Effects
❑
Parametric Equalization
❑
3D Spatialized headphones
❑
4-channel surround and adjustable
playback speed
Playback Speed
❑
Up to 2x faster or slower for audio
book content, .WAV files and up to
1.4x faster for MP3 and up to 2x
slower for MP3 audio playback
Audio Codec Support
❑
MPEG Audio Layer 3 (MP3), WAV and
future formats (WMA)**
SDMI Compliance
