Crestron TSW-70 Series User Manual

Product Manual — Doc. 8550E TSW-70 Series • 11
Advanced Touch Screen Control
The TSW-570PR offers a sleek and powerful user interface for controlling technology in the
home via the Crestron Home app. The touch screen provides an intuitive interface that is fully
customizable with easy-to-use capacitive controls, true feedback, and real-time status display.
Abuilt-inproximity sensor wakes the screen without requiring any user interaction, and
automatic brightness controls ensure optimal visibility under varying lighting conditions.
Streaming Video
Native support for H.265, H.264, and MJPEG formats allows the TSW-570PR to display live
streaming video from an IP camera, a streaming encoder (Crestron DM-TXRX-100-STR, or
similar), or a DigitalMedia™ switcher.
1
Video is delivered to the touch screen over Ethernet,
eliminating the need for any extra video wiring.
Crestron Home OSControl
The TSW-570PR may be used to control a Crestron Home™ OS whole home solution. Select the
Crestron Home app from the touch screen to control lighting, shades, climate, media, security,
and cameras, including the ability to create and recall scenes that create a desired ambiance
throughout a home. A TSW-570PR may be installed in each room to provide easy access to
various Crestron Home functions for both the room and the home.
Wired Connectivity
An Ethernet LAN connection is all that is required to wire the TSW-570PR, containing all control,
video, and power signals within a single wire.
Power over Ethernet
Using PoE technology, the TSW-570PR gets its operating power directly through the network
cable. PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated
power wiring. Crestron PoE switches (CEN-SW-POE-5 or CEN-SWPOE-16
1
) offer a total
networking solution with built-in PoE for multiple touch screens. A PoE Injector (PWE-4803RU
1
)
is also available to support a single touch screen.
NOTE: Refer to the “Power” specifications for more details.
Enterprise-Grade Security
Crestron touch screens employ enterprise-grade networking with robust security features such
as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory® service
integration.
Wall Mount Options
The TSW-570PR is easily installed into drywall and other surfaces using the included
TSW-UMB-70 universal mounting bracket, which affords the following mounting options:
2
l
Can be used by itself as a postconstruction solution for retrofitting the TSW-570PR into
existing drywall.
