TSW-570 Specifications
Product specifications for the TSW-570 are provided below.
Product Specifications
Touch Screen Display
DisplayType TFT active matrix color LCD
Size 5 in. (127 mm)diagonal
Aspect Ratio 16:9 HD720
Resolution 1280 x 720 pixels
Brightness 400 nits (cd/m
2
)
Contrast 800:1
Color Depth 24 bit, 16.7M colors
Illumination Edgelit LED with auto brightness control
Viewing Angle ±80° horizontal, ±80° vertical
Touch Screen Projected capacitive, 5-point multitouch capable
Buttons
Virtual Buttons (5) Virtual buttons in collapsible universal tool bar, per-button show/hide,
preconfigured with icons for Power, Home, Lights, Up, and Down, optional
custom programming via control system for additional functions
Reset (1) Pin hole on rear panel for hardware reset
Graphics Engine
Crestron HTML5 and Smart Graphics® software technology, multilanguage web browser
3
, multilanguage
onscreen keyboard, screensaver, single scalable streaming video window, native room scheduling
application
2
, native Crestron Home™ OSapp,setup and diagnostics via web browser, cloud, or onscreen UI
Room Scheduling Support
Crestron Scheduling App CrestronFusion® software, Microsoft Exchange Server® and Office 365®
software, Google Calendar™ calendaring app and G Suite™ software,
CollegeNET® 25Live® software, and Ad Astra™ software (IBM® Notes® software
is also supported through Crestron Fusion on-premises server only)
2
