Crestron TSW-70 Series User Manual

Product Manual — Doc. 8550E TSW-70Series•1
Overview
The Crestron® TSW-570, TSW-570P, TSW-770, and TSW-1070 are wallmounttouchscreens
that feature web browsing, Smart Graphics® software andHTML5UItechnology,
custom-programmable virtual buttons, H.265/H.264 streaming video, a Rava®SIPintercom
(TSW-770 and TSW-1070 only), Wi-Fi® network connectivity (TSW-770 andTSW-1070only),
and PoE+(PoweroverEthernetPlus)network power. Thetouchscreensalsoprovidebuilt-in
applications for room scheduling, conferencing, and home control.
NOTE:TheTSW-570,TSW-570P,TSW-770,andTSW-1070arefunctionally similar. For
simplicity within this documentation, the term "touch screen"is used except where otherwise
noted.
Crestron offers the following variations for its standard touch screen models. Certain settings
described in this document are not applicable to these models.
l
The TSW-770-GVandTSW-1070-GVseries touch screens eliminate the microphone, the
Bluetooth® communications beacon, and Wi-Fi network connectivity to comply with
government applications demanding extra privacy and security.
l
The TSW-570PR, TSW-770R,andTSW-1070Rseries touch screens are designed
specifically to run the Crestron Home™ OShome control application.
Features
Refer to the following sections for more information on the features provided by various TSW-
70 Series models.
l
TSW-570 Features (on page2)
l
TSW-570P Features (on page6)
l
TSW-570PR Features (on page10)
l
TSW-770 Features (on page13)
l
TSW-770-GV Features (on page20)
l
TSW-770R Features (on page25)
l
TSW-1070 Features (on page29)
l
TSW-1070-GV Features (on page36)
l
TSW-1070R Features (on page42)

Crestron TSW-70 Series Specifications

General

Brand	Crestron
Model	TSW-70 Series
Category	Touch Panel
Language	English
