Crestron TSW-70 Series User Manual

116 • TSW-70 Series ProductManual — Doc. 8550E
TSW-770-GV and TSW-1070-GV
Installation
Use the following procedures to install the TSW-770-GVandTSW-1070-GVtouch screens.
Install the Mounting Bracket
The TSW-770-GV and TSW-1070-GV install over a standard 2-gang or 3-gang U.S. electrical box,
a 2-gang European electrical box, or a 2-gang U.K. electrical box. The touch screen also installs
into drywall.
NOTES:
l
Additional mounting options are possible using the following mounting accessories. For
more information, refer to the product pages at www.crestron.com.
o
TSW-UMB-70 universal mounting bracket
o
TSW-UMB-70-PMK preconstruction mounting kit
o
TSW-UMB-70-BBI wall mount back box
o
TSW-770/1070-MSMK series multisurface mounting kits
o
TSW-770/1070-MUMK mullion mounting kit
o
TSW-770/1070-RMB series retrofit mounting brackets
o
TSW-770/1070-RMK series rack mount kits
l
Installing the mounting bracket to an electrical box is required only if one of the
mounting solutions above is not used. Refer to the documentation for your chosen
mounting solution at www.crestron.com/manuals.
Electrical Box Mounting
To mount the touch screen into an electrical box, use the appropriate screws (four 6-32x3/4in.
screws, four M3x16mmscrews, or two M3.5x25 mm screws) to attach the mounting bracket to
the electrical box as shown in the following illustrations:
NOTE:ForU.S. installations, use a #2 Phillips screwdriver. For European or U.K. installations,
use a #1 Phillips screwdriver.

Crestron TSW-70 Series Specifications

General

Brand	Crestron
Model	TSW-70 Series
Category	Touch Panel
Language	English
