SG250 Owner’s and Service Manual
www.CSCMotorcycles.com
21
Front Brake Pad Inspection and Replacement
It is possible to check the thickness on the front brake pads without removing the caliper from the
motorcycle, but it is difficult to do so and get an accurate indication of brake pad thickness. It is better to
remove the caliper to better see the pads.
The front brake caliper is located on the left side of the
motorcycle.
Loosen the front brake caliper’s two 5mm Allen pins.
Pull the caliper off the brake disk. You should not remove
the hydraulic, nor should you loosen it.
Completely remove the caliper’s two 5mm Allen pins, and
remove the two brake pads.
Note that one of the brake pads has a wear groove machined into the pad surface. When the pad is
worn such that the wear groove is no longer visible, replace both pads with new pads. CSC stocks
these pads, so call us at 909 445 0900 if you need to order a pair.
