SG250 Ownerās and Service Manual
www.CSCMotorcycles.com
29
Clutch Cable Installation and Adjustment
Route the cable from the handlebar (without attaching it yet)
to the engine. Note that there is a loop welded on the left
front frame downtube through which you should route the
clutch cable.
Apply a small amount of grease to the lower clutch cable
attachment point and attach the lower end of the clutch
cable to the engine clutch arm. This is what it will look like
looking down at the attach point between the engine and
the exhaust pipe.
Route the clutch cable through the adjustment mount on the
engine, and adjust the adjustor nuts to give the cable as
much slack as possible. The barrel should reach as far back
to the rear of the motorcycle as it can.
Pull back the handlebar clutch lever hood.
