Loosen the Phillips head screw securing the airbox inlet to
the carburetor.
Detach it from the carburetor.
Unscrew the carburetor slide assembly cap and remove the
carburetor slide assembly from the carburetor.
Pull the slide out of the carburetor body.
Remove the two 10mm nuts securing the carburetor to the
intake manifold.
