CSC SG250 - Page 73

SG250 Owner’s and Service Manual
www.CSCMotorcycles.com
73
Gently push the float pivot shaft out of the carburetor body.
Lift the float and the float valve from the carburetor
body. Take care not to drop the float valve; it will fall off of
the float when the float is tilted.
These arrows identify the float valve and the pivot.
This is the float valve.
Remove the main, slow, and idle jets from the carburetor
with a flat head screw driver.
