Remove the acorn nuts.
Slide the exhaust header flange away from the cylinder head
Loosen the 10mm bolt securing the exhaust header-to-
muffler clamp.
Remove the 10mm bolt securing the forward end of the
muffler to the motorcycle frame.
Remove the 10mm bolt and nut securing the muffler to the
motorcycle frame on the right side of the motorcycle
beneath the seat.
