Chapter 4. Console Port Operation
49
May 2011
The menu items are pretty self-explanatory. First setup the TCP/IP settings for IP, mask and
gateway. The Device Name is the "sysName" which will be reported via the SNMP standard MIB2.
The TFTP server IP is the IP address of the server used to hold the upgrade image and from which
the ETU-01A SNMP will download the upgrade image during an upgrade process. The TFTP
Server Path contains the filename (case sensitive) of the upgrade image.
Select item 2, Manager Config.
Use items 1&2 to set the SNMP community string variables. One variable is for Read/Write
access (can do SNMP set as well as get), while the other variable is the Read Only string (SNMP
manager can only perform get operations). The SNMP Agent holds space for up to 8 manager IP
addresses (select 3~A). Each manager can be configured to receive traps or not and each manager is
given authority by assigning it either the R/W or Read community string.
IMPORTANT:
After doing any configuration of the SNMP agent, the settings must be saved and the agent
rebooted. Select item 4, Save & Restart, from the SNMP Agent Setup Menu.
Upgrade:
When we release new upgrade firmware, it is always packaged in a ZIP file and available for
download from our website. The ZIP file will include the following files:
1. The upgrade image file with "bin" file extension.
2. A free Windows TFTP server application that requires no installation.
3. A PDF file with detailed procedure to upgrade the SNMP agent.
Since upgrade packages already include the detailed upgrade procedure, the procedure will not
be covered in this manual.
<< Manager Config >>
1 Community #1 (R/W) : [secret]
2 Community #2 (Read): [public]
3 Access IP #1 : [172. 24. 1.125] [Community #1] [Trap]
4 Access IP #2 : [172. 24. 1.251] [Community #1] [Trap]
5 Access IP #3 : [192.168. 0. 49] [Community #1]
6 Access IP #4 : [ 0. 0. 0. 0] [Community #1] [Trap]
7 Access IP #5 : [ 0. 0. 0. 0] [Community #1] [Trap]
8 Access Ip #6 : [ 0. 0. 0. 0] [Community #1] [Trap]
9 Access Ip #7 : [ 0. 0. 0. 0] [Community #1] [Trap]
A Access Ip #8 : [ 0. 0. 0. 0] [Community #1] [Trap]
Enter 1-A or Press "ESC" to previous menu.
