Cub Cadet EX2900 - Lubricating Grease Fittings on the Tractor

14-18
14. PERIODIC SERVICE
Ex2900 / 3200 Operator's Manual
1. Lubricating Grease Fittings on the Tractor
[Extremely wet or muddy conditions]
Lubricate the grease fittings once every 10 operating
hours or once a day.
[All other conditions]
Lubricate the grease fittings once every 50 operating
hours.
(A) Right tie rod end
(B) Left tie rod end
(C) Axle pivot pin
NOTE:
●The link grease fittings are located below the foot
platform on the tractor.
(D) Link grease fittings
NOTE:
●Grease fittings are located on the cross-shaft below the
center of the tractor.
3013707
(A)
(B)
A3013719
(C)
A3013718
3013710
(D)
