Cub Cadet EX2900 - Replacing the Tail Light Bulb; Replacing the Turn Signal; Hazard Lights Bulb

15-8
15. SERVICING THE ELECTRICAL SYSTEM
Ex2900 / 3200 Operator's Manual
■ Replacing the Tail Light Bulb
NOTE:
●The tail light can be serviced after removing the front or
rear lens assembly.
1. Park your tractor safely.
2. Stop the engine and remove the key.
3. Remove the two screws and lens from the assembly.
4. Push down and rotate the bulb to remove it.
5. Push the new bulb into the socket and rotate to lock it
into position.
6. Check that the tail light lights normally.
7. Install the lens.
(A) Screw
(B) Lens
(C) Bulb
■ Replacing the Turn Signal / Hazard Lights
Bulb
NOTE:
●The turn signal / hazard lights can be serviced after
removing the front or rear lens assembly.
1. Park your tractor safely.
2. Stop the engine and remove the key.
3. Remove the three screws and lens from the light
assembly.
4. Push down and rotate the bulb to remove it.
5. Push the new bulb into the socket and rotate to lock it
into position.
6. Check that the turn signal / hazard lights operate
normally.
7. Install the lens.
(A) Screw
(B) Lens
(C) Bulb
(A)
A3013710
P3013719
(C)
(B)
P3013717
(A)
(B)
P3013718
(C)
