8-9
8. OPERATING THE TRACTOR
Ex2900 / 3200 Operator's Manual
6. Raise the implement.
1. Move the 3-point hitch control lever backward to raise
the implements installed to the rear-and mid-mounts.
2. If the tractor has any implements that use the
implement control valve, raise them using the
implement control lever.
(A) 3-point hitch control lever
(B) Implement control lever
7. Disengage the parking brake.
1. Depress the parking brake lever downward.
NOTE:
●Now, the parking brake lever incompletely lowers.
2. Fully depress the brake pedal.
NOTE:
●Now, the parking brake lever completely lowers.
3. Remove foot from the brake pedal. Check that the
brake pedal is unlocked.
(A) Parking brake lever
(B) Brake pedal
●Do not drive the tractor with the parking brake
engaged. Otherwise, the clutch disk can be
damaged.
8. Release foot from the brake pedal.
9. Slowly depress the forward or reverse
drive pedal.
CAUTION
3013703a
(B)
(A)
A3013703
(A)
(B)
To Next Page
