CUES Inc., MPlus+ User Manual | CH905
www.cuesinc.com, | salesinfo@cuesinc.com
EXPLODED VIEW DRAWINGS & BOM’S
LATERAL PUSH SYSTEM COILER ASSEMBLY, MPLUS+, Rev. H, CH300
Item # Description P/N Qty
0001 BEARING,BRAKE,BASKET ASSY CH174 1
0002 BEARING,SR&ENCODER,MPLUS+ CH002 1
0003 FLANGE,BEARING SR&ENCODER MPLUS+ CH003 1
0004 JACK SHFT,BEARING SR&ENCODER MPLUS+ CH004 1
0005 COVER,BEARING SR&ENCODER,MPLUS+ CH005 1
0006 HANDLE,ADJUSTBLE,BLK,NYL 5/16-18,SS HW2907 1
0007 SLIPRING,MOOG SRA-73540,2A,120V EC1976 1
0008 ASSY,BASKET WELDMENT,LAT MPLUS CH011 1
0009 SHAFT BUSHING,BASKET ASSY, MPLUS+ CH014 1
0010 CLAMP,TUBING INSULATED,1/2” 121104 2
0011 GUIDE,CABLE,RING, F/CH300 COILER CH006 1
0012 ENCODER,OPTICAL KIT,OEM EC2054 1
0013 CONNECTOR,BULKHD,FM,8PIN,LUMBERG EC274 1
0014 WASHER,FLAT,#8 SST 100139 2
0015 SCREW,CAP,SKT HD,8-32X7/8,SST 103067 2
0016 SCREW,CAP,SKT HD,6-32X3/8,SST 105071 4
0017 PLATE,MNTG,CONN EC2080 CH037 1
0018 SCREW,CAP,SKT HD,4-40X3/8,SST 100054 3
0019 O-RING,2-023,BUNA-N HW731 1
0020 SCREW,SHCS,8-32X3/8 SST 100448 4
0021 O-RING,2-035,BUNA 7124 1
0022 SCREW,CAP,SKT HD,6-32X1 1/2 SST 100114 2
0023 SEAL,OIL,1.00ID X 1.43 OD,VITON,SST HW4039 2
0024 PLATE,CONNECTOR MOUNT,MPLUS+ CH063 1
0025 O-RING,2-118 EP 132208 1
0026 SCREW,CAP,SKT HD,8-32X1/2,SST 101025 4
0027 CABLE ASSY,BASKET>SLPRING/ENCDR,MP+ CH331 1
0028 BLACK PUSHNUT FASTENER,3/4” SHAFT HW2646 2
0029 SHAFT COLLAR,ACETAL,.75 BORE X.50W HW2882 2
0030 MOUNTING BRACKET,COILER ASSY,MPLUS+ CH019 1
0031 FRAME ASSY,LATERAL PUSH SYS, MPLUS CH302 1
0032 TERMINAL,SOLDER LUG,LOCKWASHER #6 HW2641 2
0033 TUBE,SHRINK,BLACK 1/8” 712789 1
0034 SCREW,CAP,SKT HD,1/4-20X5/8,SST 101024 4
0035 WASHER,SPLIT LOCK,1/4”SST 101740 5
0036 WALKER TIP, .875 DIA, RUBBER, BLK HW2971 7
0037 WASHER,FLAT,1/4”SST 101736 2
