CUES Inc., MPlus+ User Manual | CH905
www.cuesinc.com, | salesinfo@cuesinc.com
EXPLODED VIEW DRAWINGS & BOM’S
LATERAL PUSH SYSTEM COILER ASSEMBLY, MPLUS+, Rev. H, CH300
Item # Description P/N Qty
0038 NUT,HEX,SST,1/4-20 101040 2
0039 KNURLED KNOB,.375-16X3.0LG,303SST HW2883 1
0040 CAP,RIGID,PLASTIC, .375 THREAD HW2506 1
0041 CAP,ROUND,PUSH-ON,.25 OD,EDPM HW2503 2
0042 WHEEL,COILER ASSY,LATERAL PUSH SYS CH010 2
0043 PLUNGER,NYLON KNOB,.2 DIA X .2 LG HW2434 1
0044 WASHER,FLAT,5/16 USS PLD 101132 7
0045 SWIVEL MOUNT,1.5 BALL,RAM,SPECIAL HW2501 1
0046 LOCK,SPLIT COLLAR,7/8 TO 5/8-BSTYLE CH097 2
0047 SNAP BUTTON,SINGLE END, 0.25OD HW4022 2
0048 WASHER,2”ODX0.37 IDX.37 THK,BLK HW2914 1
0049 SCREW,CAP,SKT HD,10-32X3/8,SST 103030 4
0050 PLUG,HOLE F/3/4” HOLE HW899 1
0051 MRO-REMOVABLE LCK,ND 121200-2,BLUE CS036 1
0052 MRO-LOCTITE #411 INSTANT ADHESIVE CS572 1
0053 MRO-TIE,CABLE,3/32” X 4”,BLACK CS444 1
0054 WIRE,#22AWG,BLACK,PVC,STRD EC407 0.25
0055 TUBE,SHRINK,BLACK 3/8”RNF 712586 1
0056 GRIP,FOAM TUBE,EPDM, .562ID,INCHES CH098 6.5
0057 DECAL, TOP SUPPORT PLATE, MPLUS+ CH112 1
0058 GLUE,GRIP,SCOTTS,4ML CS597 1
0059 MRO-ANTI-SEIZE,LPS NICKEL,P/N 03908 CS407 1
0065 MRO-GREASE,SUPERLUBE 21060 - 3 OZ HW039 1
0066 WASHER,SPLIT #6 SST 100150 4
0067 WASHER,SPLIT LOCK,#8 SST 101738 4
0068 NUT,LOCK NYLON INS,SST,8-32 112532 2
0069 SCREW,CAP,SKT HD,1/4-20X1,SST 101065 2
0070 NUT,LOCK W/NYL INS 1/4-20 SST HW030 2
