5.2 Intelligent Photoelectric Sensing
The intelligent photoelectric port of this controller supports photoelectric through-
beam or reflection sensors composed of light-emitting diodes and phototransistors,
and can also be set to support NPN or PNP switch sensors. The specific wiring
diagram is as follows：
B1
B2
B3
B4
GND
GND
RX
TX
Switch sensor connection method
Photoelectric sensor connection method
White Wire
Red Wire
Copper Wire
Copper Wire
The working distance of the sensor can be adjusted by setting the
P parameter, the smaller the parameter, the more sensitive it is.
Brown+
Blue-
Black OUT
GND
Signal
+24V Output
Set NPN or PNP type by parameter P
Photosensor
Photosensor
Speed Ctrl
Speed Ctrl
Sensor
Sensor
Ctrl Out
Ctrl Out
SDVC311 Series
Variable Frequency Digital Controller for Vibratory Feeder
