Waveform Index Diagram

r=100 r=0

The wave index value of 0 has the highest efficiency and the least stress on the

spring.

When the value is 100, the maximum rated output power and minimum noise can

be obtained, but the spring will be subjected to greater stress.

Variable Frequency Digital Controller

for Vibrat

ory Feeder

Saturated Accelerate

Remote

Stop

Lock

Voltage

Frequency

On Delay

Off Delay

Soft Start

SDVC311-M

5.7 Waveform Index

The controller can continuously balance the performance of the highest efficiency-

maximum power and minimum noise to meet the higher demands of customers.

This can be achieved by setting the parameter value of the advanced parameter

"waveform index r".

r means

Waveform Index

Default setting: 100

current current

time time

SDVC311 Series

Variable Frequency Digital Controller for Vibratory Feeder
