Culligan G1 Series User Manual

G1 RO International 113
Cat. No. 01021713
G1 Membrane Vessel, International
End Cap
Retaining Rings
Screws
O-Rings
FLOW
Membrane
Housing
1
2
3
4
Brine Seal
Figure 65. G1 membrane vessel.
Item Part No. Description 2S 3S 2L 3L 4L
01025333 Assembly, Membrane Housing, Single, 2.5"x21" 2 3
01025334 Assembly, Membrane Housing, Single, 2.5"x40" 2 3 4
1 01025336 Housing, FRP, 2.5"x21"with endcaps 2 3
1 01025335 Housing, FRP, 2.5"x40"with endcaps 2 3 4
2 01024288 RO Membrane, 2.5"x21" 2 3
2 01024289 RO Membrane, 2.5"x40" 2 3 4
3 01025324 End Plug Assy 2.5", metric 4 6 4 6 8
4 01023072 O-Ring kit 2.5"
01023411 Clamps, RO Housings, 2.5", metric 2 3 2 3 4
