G1 RO Parts Diagrams and Lists 81
Cat. No. 01021713
G1 RO Series 2S 3S 4S 2L 3L 4L 1F 2F
Item Part No. Description Qty Qty Qty Qty Qty Qty Qty Qty
1 01024508 Motor Panel Assembly, G1-2S, 3S, 4S 1 1 1
1 01024517 Motor Panel Assembly, G1-2L, 3L 1 1
1 01024518 Motor Panel Assembly, G1-4L 1
1 01024519 Motor Panel Assembly, G1-1F, 2F 1 1
2 01021992 Assembly, Feed, G1 1 1 1 1 1 1 1 1
3 01021993 Assembly, Return, G1 1 1 1 1 1 1 1 1
4 01021994 Assembly, Drain w/Solenoid Flush, G1 1 1 1 1 1 1 1 1
5 01024512 Assembly, Product Flow Meter, G1 1 1 1 1 1 1
5 01024520 Assembly, Product Flow Meter, G1-1F, 2F 1 1
6 01021997 Assembly, Pressure Gauge, G1/Q1/V1 1 1 1 1 1 1 1 1
7 01022855 Pump, Rotary Vane, Brass, 100 GPH 1 1 1
7 01023798 Pump, Rotary Vane, Brass, 165 GPH 1 1
7 01023800 Pump, Rotary Vane, Brass, 190 GPH 1
7 01022106 Pump, Rotary Vane, Brass, 330 GPH 1 1
8 01022856 Motor, 1/3 HP, 115V, 1725 RPM, Nema
Frame 48Y, Carbonator Mount Style
1 1 1
8 01022107 Motor, 3/4 HP, 115V, 1725 RPM, Nema
Frame 48Y, Carbonator Mount Style
1 1 1 1 1
9 01022033 V-Band, Pump/Motor 1 1 1 1 1 1 1 1
10 01021033 Flow Meter, Inlet, 1/2" NPT—see page 22 1 1 1 1 1 1 1 1
– 01022706 Flow Meter, Inlet, 1/2" NPT 1 1 1
11 01025480 Filter Housing, 10" BB 1 1 1 1 1 1 1 1
12 01022387 Cartridge Filter, 5 micron, 10" 1 1 1 1 1 1 1 1
13 01022145 U-Bend, PI 1 1 1 1 1 1 1 1
14 01022144 Check Valve, Inline 1 1 1 1 1 1 1 1
15 01024455 Bracket Kit, Wall Mount 1 1 1 1 1 1
15 01024484 Bracket Kit, Wall Mount 1 1
16 01023412 Assembly, Membrane Housing, Single,
2.5"x21"
2 3 4
16 01023417 Assembly, Membrane Housing, Single,
2.5"x40"
2 3 4
16 01022875 Assembly, Membrane, Single, 4”x40” 1 2
17 01021977 GROC Controller—see page 10. 1 1 1 1 1 1 1 1
18 01025825 Cable, Meter, 48"L w/ Strain Relief 1 1 1 1 1 1 1 1
