Auxiliary Contacts
Aux Output 2 Example
As mentioned above, for CSM and Hi-Flo 50 softeners, this output is used for the refill solenoid. As an example,
let’s say we have a CSM-300-2 and we need to set this up for refill minutes. We are looking for a capacity
around 250,000 grains (10 lbs/ft³).
According to the chart on page 92 of the CSM installation manual (01016370), we are looking at a salt dosage
of 10.2 lbs/ft³ and need to set the ON minutes of AUX2 to 17.
Here is how to set this up:
Scroll to ACCESSORIES and select
Scroll to AUX OUTPUTS and select
Scroll to AUX OUT 2 and select
Leave this set at NORMALLY OFF. We want the output to energize (turn on) the refill
solenoid
This should be set to SERVICE POS.
No delay is necessary.
For our example, this would be set to 17.
AUX OUTPUT 3 has the same menu options. Refer to the chart on page 48 for quick reference.
Auxiliary Contacts 48
47 CULLIGAN GLOBAL ELECTRONIC CONTROLLER
> 4) accessories
> 4) aux outputs
> 2) aux out 2
3) aux out 3
system ok
7:32 am 2-1-08
aux2 cycle type
normally off
aux out 2
service pos
aux2 out
delay 0 mins
aux2 out
on 0 mins
