GUARD KIT, TG LATCH CYL, QUS
04991
1:6
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
1
3
24
5
.
3
3
M
I
N
TO
P
E
D
G
E
ITEM NO. PART NUMBER QTY. DESCRIPTION
5 00-61035-00-OA 2 SPACER, TG GUARD, QUS
4 485-004-001 4 WASHER,SAE FLAT
3 485-008-004 4 WASHER,LOCK
2 415-004-012 4 CAPSCREW, 1/4-20 X 3/4
1 00-60851-00-OA 2 GUARD, TG LATCH CYL, QUS
