CURBTENDER Quantum Compact - Page 85

SYM
1
2
3
4
5
6
REVISION RECORD BY DATE
DRAWN BY
CHK'D
SCALE
DATE
APP'D
WEIGHT
DRAWING NO.
DATE
PLOTTED
WAS 4" & .33'
MG
WAS 300-017-001
CLB
ADDED TABLE
RLK
ADDED
MG
12/86
03/93
09/16/87
08/21/91
MLK 11/06/95
MLK 11/06/95
REDRAWN ON CAD: 12-24 VOLT
REPLACES 6-36 VOLT ALARM
RED WIRE ADDED & HEAT
SHRINK REPLACES INSULATION
WAYNE ENGINEERING CORP.
CEDAR FALLS, IOWA
DIMENSIONS SHOWN (X.XX) ARE FOR REFERENCE ONLY.
01/04/83
(EXCEPT AS NOTED)
TOLERANCES
AB-14638-00
AB-14638-00
ALARM ASSEMBLY
1:1
SYM PART NUMBER QTY NAME
1
2
3
1
310-005-000
R3-45116-11
R7-52003-80
R7-52002-80
R3-45116-02
DSS
4
5
6
7
PART NUMBER
AB-14638-00
638-012-024
*AB-14638-24
638-012-001
SYM 6
24
12-24
VOLTS
8 300-017-000 2
9
SEE TABLE
BACK - UP ALARM
2
RING TERMINAL
WIRE - RED 16 GA
3/16 HEAT SHRINK
1/8 HEAT SHRINK
.33'
WIRE - DARK BLUE 16 GA
.50'
.21'
.17'
R3-45116-06
.33'
WIRE - GREEN/BLACK 16 GA
DIODE
R3-451116-01
.58'
WIRE - BLACK 16 GA
3 PLACE DECIMALS ± .010
2 PLACE DECIMALS ± .03
ANGULAR ± 1°
BLACK 7"
BLUE 4"
RED 2 1/2"
6"
2 1/2"
*OBSOLETE - REPLACED BY AB-14638-00
VIEW SHOWING
DIODE POSITION
SOLDER
8
5
SOLDER
1
6
6
6
4
GREEN/BLACK
STRIPE 4"
7
9
6
4
3
2
1
