CURBTENDER Quantum Compact - Page 84

21 22 23 24
SEE SWITCH DETAIL
SWITCH DETAIL
SCALE 2:1
1
BY ECN NUMBER SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
DESCRIPTION
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
5
6
7
8
ECN RELEASE
00-36314-00-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-36314-00-AB
7/17/2017
ELEC ASSY, TAILGATE, PLS
03047
DAS
1:6
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ATTACH BLUE WIRE 177A
ATTACH RED WIRE 012I
ATTACH TO BLUE WIRE 147E
SHEET 3 OF 3
SHEET 3 OF 3
22
