3.36
54.55
53.04
.38
8
STRINGER ONLY
WELD TO BODY
SCALE 1:8
SEE NOTE B
7
3 SIDES
HOLD DOWN DETAIL
.19
4
RISER WLD
CHASSIS FRAME
6
5
14.50
9.00
TRUCK FRAME
DRILL .656 THRU
1
TO INSURE CLEARANCE.
FRAME RAIL ON THE BODY STRINGER AS REQUIRED
MOUNTER MUST PROVIDE SPACERS BETWEEN THE LOCATE REAR HOLD DOWN
BETWEEN THE AXLE CENTER
AND REAR FRAME OF BODY
MUD FLAP AND THE EXHAUST PIPE.
CHASSIS FRAME RAIL.
THE BODY STRINGER, SHIM WITH 00-31365-01-OA THRU 00-31365-06-OA ON THE
NOTE B: SHIM THE HOLD DOWN WITH #00-34965-01-OA THRU 00-34965-02-OA ON
CHASSIS COMPONENTS.
POSSIBLE WHILE MAINTAINING 2.00 OF CLEARANCE BETWEEN THE BODY AND THE
SHEET 1 OF 2
NOTE C: USE 00-31941-00-AA WHEN NEEDED TO AVOID CONTACT BETWEEN THE
A FLAT SURFACE
SO THAT THE BODY STRINGER RESTS ON
MOUNTER MUST PROVIDE A SPACER
NOTE A: SOME CHASSIS MANUFACTURES WARN AGAINST THE FRONT OF THE
BODY EXTENDING BEYOND A MARKED POINT ON THE CHASSIS FRAME RAIL. FOR
WAYNE ENGINEERING CORP BODIES THIS WOULD APPLY TO THE END OF THE BODY
STRINGER (THE MEMBER THAT ACTUALLY CONTACTS THE FRAME RAIL) NOT THE
FRONT OF THE BODY. THE BODY SHOULD BE MOUNTED AS FAR FORWARD AS
IF CHASSIS FRAME RAILS HAVE RIVETS
HEADS ON THE TOP FLANGE. THE
CHECK DISTANCE OF TIRE ABOVE FRAME RAIL WHEN
THE REAR SUSPENSION ID BOTTOMED OUT. THE
43
2
MTG KIT # ITEM 6 #
00-36309-11-AB 00-39189-01-OA
00-36309-12-AB 00-39189-02-OA
00-36309-13-AB 00-39189-03-OA
4.78
6 YD, 108.00 8 YD, 120.00 10 YD84.00
SEE NOTE A
MIN
6 YD, 140.00 8 YD, 152.00 10 YD
2.00
116.00
56.89
94.00 6 YD, 118.00 8 YD, 130 10 YD
41.50
6.00
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
DESCRIPTION
7
6
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
5
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
00-36309-1X-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-36309-1X-AB
10/01/09
PARTS ASSY, MTG W/ 4" RISER, QUS
04278
DAS
1:24
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ITEM NO. PART NUMBER QTY. DESCRIPTION
14 00-39194-00-OA 4 END CAP, 4 X 3 TUBE, QUS
13 445-006-002 10 NUT,LOCK
12 485-006-003 20 WASHER,STD FLAT
11 415-006-016 10 CAPSCREW
10 00-36300-02-AB 1 FENDER WLD, RH, PLS
9 00-36300-01-AB 1 FENDER WLD, LH, PLS
8 445-710-001 8 NUT, FRAME
7 416-710-032 8 BOLT, FRAME, HEX FLANGE
6
SEE CHART<As
Machined>
2 TUBE, STRINGER RISER, QUS
5 00-36025-02-OA 4 HOLD DOWN, 4" TALLER, QUS
4 400-025-002 4 COTTER HAIRPIN
3 303-012-022 4 GROMMET
2 00-36244-04-OB 1 COVER, RH TAILGATE, PLS
1 00-36244-03-OB 1 COVER, LH TAILGATE, PLS
STRINGER TUBE TO STRINGER
WELD INSIDE WHERE POSSIABLE
.13
4
2-12
.19 2-12
2
614
END CAP TO STRINGER TUBE
