.19 2-8
147.75 FROM BACK OF CAB 8 YARD
RELOCATE REAR TOP BOLT HERE
165.25 FROM BACK OF CAB 10 YARD
124.25 FROM BACK OF CAB 6 YARD
CUT CHASSIS FRAME RAIL
AND FUEL FILLER BRKT
2.37
4.75
11.00
1.43
2
3 SIDES.19
.19
INSTALL THIS END OF SPILL SHEILD .25 PAST CHASSIS FRAME
1
ISUZU CHASSIS FRAME
RISER TUBE 00-39189-XX-OA
CUT OFF ISUZU FILLER BRKT TO 4.75 LONG
2
.
1
1
4
.75
8
BY
ECN NUMBER
SYM
DIMENSIONS IN () ARE REFERENCE
ANGULAR ± 1°
2 PLACE DECIMALS ± .06
3 PLACE DECIMALS ± .005
TOLERANCES
(EXCEPT AS NOTED)
DRAWING NO.
DATE
SCALE
CHK'D
DRAWN BY
DATE
DESCRIPTION
7
6
This drawing is loaned to you and is to be returned upon our request.
1
2
3
4
5
This drawing and the information thereon is the property of WAYNE ENGINEERING CORPORATION. It may not be
copied, duplicated, reproduced or used in any way to the detriment of WAYNE ENGINEERING CORPORATION.
ECN RELEASE
00-60588-00-AB
ECN
ECN
ECN
ECN
ECN
ECN
ECN
ECN
00-60588-00-AB
03/14/11
SHEILD INSTALL, SPILL, QUS
04823
DAS
1:10
CEDAR FALLS, IOWA
ENGINEERING CORPORATION
ITEM NO. PART NUMBER QTY. DESCRIPTION
1 00-39999-00-OA 1 SPILL SHEILD, ISUZU, QUS
