Currie tech Izip E3 Path - PAS;TAG System Operation; PAS;TAG System Controls; TAG Mode Operation

38
39
Press to turn on the bicycle
Afterpressing‘Power’,alltenmeterlightswillashinse-
quence, indicating that the bike is ready to ride.
To turn the bicycle off, hold the 'ON/OFF' button for about
3seconds.
E3Ultra:
Do not put any pressure on the pedals during startup.
Doing so may affect the pedal-force sensor calibration (the
pedal-force sensor’s zero-point is re-calibrated each and
every time the power is turned on).
The BATTERY lights display remaining
charge
Themeterboxhasfivebatterylevelindicators.Thebat-
tery pack reports state-of-charge (SoC) information to
the controller and the meter box uses this information to
display the battery level with high accuracy.
When the battery is depleted to the point of automatic
shutoff, the lowest gauge light will blink indicating the need
to recharge immediately. Of course, the bicycle can still be
ridden with the system turned off.
PAS Mode: the ‘-’ and ‘+’ buttons control
motor assist power
PAS mode provides three levels of assist. You can choose
betweenthembypressingthe‘+’and‘-’buttons.Each
increasing level of assist gives more motor power, but
decreases overall range. The system defaults to assist
level 2 at startup. Regardless of the mode setting, the
Theamountofpedalpressureandtheamountofmotorassistareproportional;
harder pedaling will result in the motor providing more assistance. The throttle
acts as a “boost” once the bike is rolling, and overrides the pedal sensor when
applied.
TAG Mode
InTAGmode,thepedalsensor(E3Metro)orpressuresensor(E3Ultra)usedfor
PAS mode operation is disabled, and the bike responds only to throttle input. Just
twistthethrottletoapply0-100%ofmotorpower.The‘-’and‘+’buttonsarenot
used in this mode.
throttle is always able to provide 100% power.
E3Metro:
The motor will activate when the system senses the rider pedaling.
It is not possible to activate the motor without turning the cranks.
The throttle can act as a “boost” once the bike is rolling, but if
crank movement is discontinued, power will drop away within 1-2
seconds with or without throttle use.
E3Ultra:
The motor will activate when the system senses the rider applying
pressure to the cranks. It is not possible to activate the motor
otherwise in PAS mode. Also the bicycle must be rolling forward at
about3km/hbeforethemotorwillactivate.Thissafetyfeatureis
intended to prevent unintentional acceleration.
Mode Select (green button)
