Currie tech Izip E3 Path - Troubleshooting Electric System Issues; Troubleshooting Power and Speed Issues; Troubleshooting Electric System Faults

114
115
PROBLEM POSSIBLE CAUSE REMEDY
Bicycle has reduced range and/or
speed
Low batteries Charge batteries for recommended time
Faulty or old batteries Replace batteries
Low tire pressure Inatetirestorecommendedpressure
Brakes dragging against rim Adjust brakes and/or rim
Riding in hilly terrain, headwind, etc. Reduced range to be expected in these
types of terrain and/or weather conditions
Hub motor makes a "clicking"
noise and has reduce power and/
or shuts off
Low batteries Charge batteries for recommended time
Damaged planetary gears Replace hub motor/wheel
No power when the switch is
turned "ON"
Blown fuse Replace fuse
Loose connectors Check all connectors
Broke wire Inspect all wires for damage
Faulty switch Replace switch and retest
Faulty controller Replace controller and retest
Bicycle operates OK but battery
gauge does not light up
Loose connectors Check throttle and/or battery gauge con-
nectors
Damaged wires Inspect all wires
Faulty battery gauge Replace battery gauge
Battery gauge lights up but bicycle
does not operate
Faulty brake inhibitor Replace brake inhibitor(s) and retest
Loose motor wire connector Check motor wire connector
TMM sensor not adjusted Re-adjust TMM sensor
PROBLEM POSSIBLE CAUSE REMEDY
Bicycle runs at full speed without
pedaling
Faulty TMM sensor (Enlightened Series) Replace TMM sensor and retest
Faulty throttle Replace throttle and retest
Faulty controller Replace controller and retest
Bicycle (RMB or STB Series)
works in TAG mode but not in PAS
mode
Sensor and sensor ring not aligned Realigned so gap between sensor and
sensor ring is 1-2mm
Faulty "White Box" Replace "White Box" and retest
Battery indicates full charge when
tested at the charger port but
bicycle does not operate
Blown fuse Replace fuse
Loose connectors Check all connectors
Poor contact between battery terminals Inspect and clean battery terminals
Throttle (on bicycles so equipped)
does not spring back to neutral
position
Grip jammed against throttle Reposition grip so gap between it and the
throttle is 1-2mm
Faulty throttle Replace throttle
Bicycle has intermittent power Loose connectors Check all connectors
Loose fuse Check fuse connector
Damaged wires Inspect all wires
Charger shows a full charge in an
unusually short amount of time
Faulty charger Replace charger
Faulty batteries Replace batteries
Indicator light on charger not illu-
minated when charger is plugged
into outlet
Outlet has no power Check outlet for power
Blown fuse (Li-Ion chargers) Replace fuse
Faulty charger Replace charger
Charger (Li-Ion) indicator light
onlyashesorangeandnever
changes to red
Damage wire from charger port to battery Inspect wire
Faulty batteries Replace batteries
