Curtis PMC 1204/1205 Manual
APPENDIX C
APPENDIX C
SPECIFICATIONS
NOMINAL INPUT VOLTAGE 12V, 24–36V, and 36–48V
PWM OPERATING FREQUENCY 15 kHz
STANDBY CURRENT less than 20 mA
STANDARD THROTTLE INPUT 5 kΩ ±10% (others available)
WEIGHT 1204: 1.8 kg (4 lbs) 1205: 2.7 kg (6 lbs)
DIMENSIONS 1204: 146mm×170mm×70mm (5.75"×6.75"×2.8")
1205: 146mm×222mm×70mm (5.75"×8.75"×2.8")
NOMINAL VOLTAGE UNDER-
BATTERY CURRENT 2 MIN 5 MIN 1 HOUR DROP VOLTAGE
MODEL VOLTAGE LIMIT RATING RATING RATING @ 100 AMPS CUTBACK
NUMBER (volts) (amps) (amps) (amps) (amps) (volts) (volts)
1204-0XX 24–36 275 275 200 125 0.35 16
-1XX 24–36 175 175 130 75 0.50 16
-2XX† 24–36 275 275 200 125 0.35 16
-3XX† 24–36 175 175 130 75 0.50 16
-4XX 36–48 275 275 200 125 0.35 21
-5XX 36–48 175 175 130 75 0.50 21
-6XX 12 275 275 200 125 0.35 9
-7XX 12 175 175 130 75 0.50 9
1205-1XX 24–36 400 400 275 175 0.25 16
-2XX 36–48 350 350 250 150 0.30 21
-3XX 12 400 400 275 175 0.25 9
†
Models for use with permanent magnet motors (no A2 bus bar provided).
C-1
