Curtis 1244 Manual, Rev. E
47
battery voltage parameter can be set from 2 to 7, and should always be set to
the system’s nominal battery pack voltage:
... .. .. ...
2 24V 14V 16V 28V 31V
3 36V 22V 23.8V 43V 46V
4 48V 24V 32V 55V 61V
5 60V 37V 39V 70V 76V
6 72V 46V 49V 85V 92V
7 80V 52V 57V 97V 105V
.. = Severe Under Voltage (causes reset)
. = Under Voltage
. = Over Voltage
.. = Severe Over Voltage (causes reset)
ANTI-TIEDOwN
e anti-tiedown feature prevents operators from taping or “tying down” the
mode select switches in order to operate permanently in Mode 2 or Mode 4.
On startup, when the interlock switch is first closed, the anti-tiedown feature
checks which operational mode is selected. If the mode select switches are re-
questing Mode 2 or Mode 4, the controller will ignore the request and default
to Mode 1 or Mode 3 respectively. e controller will remain in Mode 1 or
Mode 3 until the Mode Select 1 switch is released and reactivated.
Anti-tiedown is primarily used in walkie applications. It can be pro-
grammed “On” or “O.”
SEQUENCING DLy
e sequencing delay feature allows the interlock switch to be cycled within
a set time (the sequencing delay), in order to prevent inadvertent activation of
HPD or SRO. is feature is useful in applications where the interlock switch
may bounce or be momentarily cycled during operation. e sequencing delay
parameter can be set from 0 to 3 seconds, in increments of 0.1 second, with 0
corresponding to no delay.
PEDAL INTR
e pedal interlock parameter can be programmed as “On” or “O.” When
“On,” it requires that the pedal switch input (Pin 8) be active (pulled to B+)
before the controller will supply power to the motor. is feature is useful in
systems that use a seat or foot switch to guarantee operator presence for vehicle
operation. Alternatively, a switch connected to the brake pedal can be configured
3 — PROGRAMMABLE PARAMETERS: Other Parameters
