Curtis 1244 Manual, Rev. E
67
7 — PROGRAMMER MENUS
Items are listed for each menu in the order in which they are displayed on the
programmer.
Parameters Menu (not all items available on all controllers)
V O L T A G E Nominal battery voltage, in volts
M 1 D R I V E C / L Mode 1 drive current limit, in amps
M 2 D R I V E C / L Mode 2 drive current limit, in amps
M 3 D R I V E C / L Mode 3 drive current limit, in amps
M 4 D R I V E C / L Mode 4 drive current limit, in amps
M 1 B R A K E C / L Mode 1 braking current limit, in amps
M 2 B R A K E C / L Mode 2 braking current limit, in amps
M 3 B R A K E C / L Mode 3 braking current limit, in amps
M 4 B R A K E C / L Mode 4 braking current limit, in amps
M 1 T H R T B R K % Mode 1 throttle braking, as % of brake C/L
M 2 T H R T B R K % Mode 2 throttle braking, as % of brake C/L
M 3 T H R T B R K % Mode 3 throttle braking, as % of brake C/L
M 4 T H R T B R K % Mode 4 throttle braking, as % of brake C/L
M 1 A C C E L R A T E Mode 1 acceleration rate, in seconds
M 2 A C C E L R A T E Mode 2 acceleration rate, in seconds
M 3 A C C E L R A T E Mode 3 acceleration rate, in seconds
M 4 A C C E L R A T E Mode 4 acceleration rate, in seconds
D E C E L R A T E Deceleration rate, in seconds
M 1 B R A K E R A T E Mode 1 braking rate, in seconds
M 2 B R A K E R A T E Mode 2 braking rate, in seconds
M 3 B R A K E R A T E Mode 3 braking rate, in seconds
M 4 B R A K E R A T E Mode 4 braking rate, in seconds
Q U I C K S T A R T Quick-start throttle factor
T A P E R R A T E Regen braking decrease rate when approaching zero speed, in 1/32 s
M 1 M A X S P E E D Mode 1 maximum speed, as % PWM output
M 2 M A X S P E E D Mode 2 maximum speed, as % PWM output
M 3 M A X S P E E D Mode 3 maximum speed, as % PWM output
M 4 M A X S P E E D Mode 4 maximum speed, as % PWM output
M 1 C R E E P S P E E D Mode 1 creep speed, as % PWM output
M 2 C R E E P S P E E D Mode 2 creep speed, as % PWM output
M 3 C R E E P S P E E D Mode 3 creep speed, as % PWM output
M 4 C R E E P S P E E D Mode 4 creep speed, as % PWM output
R E G E N S P E E D Minimum speed for regen braking, as % of vehicle speed
C T R L M O D E Control mode
1
T H R O T T L E T Y P E rottle type
2
T H R T L D E A D B A N D rottle neutral deadband, as % of 5kΩ pot
T H R O T T L E M A X rottle input req’d for 100% PWM, as % of 5kΩ pot
7
PROGRAMMER MENUS
